Hardware manual for PCD3 series │ Document 26-789 ENG19│ 2018-06-29
PCD3 CPUs
PCD3.Mxxx0 Classic CPU and expansion enclosure
3-9
3
basic devices
Basic Extended CAN
DP
Master
PCD3.M. 3020 3230 5340 5440 6240 6440
PCD3.M. 3120 3330 5540 6340 6540
Serial data interface
Port 2
RS-485 to 115 kBit/s
interfece
Port 2
to 187.5 kBit/s
Port 10
to 1.5
MBit/s
Port 2
to 187.5 kBit/s
Ether S-Net
interface
only
M3120
only
M3330
only
M5540
only
M6340
only
M6540
Fieldbus connections
Serial S-Net
Ether-S-Net (TCP/IP)
only
M3120
only
M3330
only
M5540
only
M6340
only
M6540
1) When using digital I/O modules with PCD3.E16x or A46x with 16 I/Os each
2) The address 255 is reserved for the watchdog on all PCD3. The I/O reserved for the watchdog can not be used
by the user, and analog and H modules must not be deployed with the slots with base address 240
3) Typical values, the processing time depends on the load on the communication interfaces
4) From HW version D and the matching FW, see detailed explanation in chapter 3.19
5)Thespecieddurationisabuertime,itdependsontheambienttemperature(ahighertemperaturemeans
ashorterbuertime)
6) The 1kHz apply to a pulse/pause ratio of 1:1 and refer to the sum of the frequencies of the two inputs
7) The USB port is of type USB 1.1 Slave Device 12 MBit/s and can only be used for programming and in
combination with certain software products (Web-Connect, ViSi-PLUS with S-Driver) as S-Bus slave.
The download works twice as fast with a USB 2.0 hub.
Can also be used as serial data interface e.g. used for connecting a terminal, however, this makes the
commissioninganddebuggingwiththedebuggerdicult.
