SBC PCD3 Series User Manual

Saia-Burgess Controls AG
Hardware manual for PCD3 series │ Document 26-789 ENG19│ 2018-06-29
Graphic list of contents
1-1
1
5560
Saia PCD3.M
1 Graphical table of contents
The graphical table of contents picks out some key aspects of the hardware
manual of the PCD3 series and allows you to jump to the appropriate chapter by
clicking on the labeled frame or directly on the component/connector. From the
table of contents you can jump to all chapters.
Plug-in serial interfaces
in slot 0…3, chapter 5.3
Battery change
chapter 8
Flash
memory
module,
chapter
3.18
Run/Stop
Switch,
chapter
3.12.2
RS-485, chapter 5
USB interface,
chapter 5.3.7
Ethernet, chapter 5 Earthing, chapter 3.9.4
Extension,
chapter 3.5
RS-485 / S-Net
(Port 10),
chapter 5.3.4
LEDs for operating status,
chapter 3.11.1
Terminal block for power
supply, watchdog, interrupt
inputs
and Port 2, chapter 3.15
LEDs for operating status,
chapter 3.11.1
Operation
mode key,
chapter
3.12.1
RS-232 /
PGU
(Port 0),
chapter
5.3.2
