Hardware and technical data
INTECONT® Tersus Belt weigher, Instruction Manual
Schenck Process Group
BV-H2464GB, 1234
- 133 -
Serial interfaces pin assignment
Pin
RS232
RS422
RS485
1 GND GND GND
2 TX Tx B RTx B
3 RX Rx B Jumper to pin 2
4 Rx A Jumper to pin 5
5 TX A RTx A
6 Jumper to pin 4 for bus termination
7 Jumper to pin 3 for bus termination
Tab. 12 : Modbus serial interface pin assignment
16.7
16.716.7
16.7
LED diagnosis
LED diagnosisLED diagnosis
LED diagnosis
Status LED
Color
Function
LNK Green Ethernet is connected
FDX Yellow Full Duplex
100 Red 100 MBaud (otherwise 10 MBaud)
ADR Green Measuring hardware is active
IDL Yellow The processor's idling time, flashes during operation
DIA Red Unused
PWR Green Power OK
SYC Yellow System cycle, flashes during operation
ERR Red Fault display, set by the system software
