Schenck process Intecont Tersus Beltweigher User Manual

Operation
INTECONT® Tersus Belt weigher, Instruction Manual
Schenck Process Group
BV-H2464GB, 1234
- 17 -
ESCAPE
Cancel a function or input and return to the actual
value displays.
ENTER
Activate a function or confirm an entry.
4.2
4.24.2
4.2 Function block
Function blockFunction block
Function block
The function distributor is the point of entry for everything that will be performed on the device. All functions
and dialogs can be called up through it. The function distributor is two-staged.
Call up the function distributor
The most recently selected function will be displayed.
Select the desired function for the first level. This field has a yellow back-
ground.
Change to the second level. The field selected for the first level has an
orange background.
Select the desired function of the second level. This field has a yellow
background.
Select function. Only those functions that can be called up at that moment
will be displayed.
Return to the normal display or abort a function.
Return to the first level.
You will return to the normal display if no key is pressed in the function distributor within 60 seconds.
Functions of the 1st stage of the function distributor:
Setup
Totals
Mode
Calibration
Parameter
