Parameters
BV-H2464GB, 1234
- 50 -
INTECONT® Tersus Belt weigher, Instruction Manual
Schenck Process Group
▪ Furthermore, each parameter has a unique ID with which it can be addressed via an interface (serial,
fieldbus). This ID can be seen as a 'Tooltip' in EasyServe when passing over the parameter and can be
output in the parameter printout.
13.1
13.113.1
13.1
Abbreviations
AbbreviationsAbbreviations
Abbreviations
FB Fieldbus
OP Operating panel
DI Digital Input
DO Digital Output
AI Analog Inputs
AO Analog Outputs
LS Logical signal for using internally available signals
Event Event. The reaction to an event can be configured
W1 Warning 1 (requires acknowledgement)
W2 Warning 2 (does not require acknowledgement)
ALARM Alarm (requires acknowledgement)
IGNORE Ignore: do not show any event message but switch the corresponding contact outputs
LC Load cell
I Feed rate
v Belt speed
VCU VCU 20100 system unit of DISOCONT Tersus. Refer to manual BVH2406 for details.
VHM DISOCONT Tersus operating panel. Refer to manual BVH2406 for details.
VMO Machine operating console for service work. Refer to manual BVH2488 for details.
Tab. 2 : List of commonly used parameter-related abbreviations
13.2
13.213.2
13.2
Configuring Event Messages
Configuring Event MessagesConfiguring Event Messages
Configuring Event Messages
The system monitors a range of both of its own operation and the peripherals. The reaction to a recognized
deviation, that is to say an event, is set by parameters. The parameters are used to assign to each event a
class that will determine this reaction.
feeding
required
Alarm ALARM Stop feeding, scales are switch-
ed off
Cannot be switched on
Yes Red
Warning 1 W1 Feeder will continue to run Yes Orange
Warning 2 W2 Feeder will continue to run No
Only display as long as
the event is active
Yellow
Ignore IG Feeder will continue to run - -
Tab. 3 : Event classes
