Web server functions
INTECONT® Tersus Belt weigher, Instruction Manual
Schenck Process Group
BV-H2464GB, 1234
- 135 -
17
1717
17
Web server functions
Web server functionsWeb server functions
Web server functions
17.1
17.117.1
17.1
Web Server
Web ServerWeb Server
Web Server
The unit is equipped with a web server that provides a homepage for the scale. This homepage is available
in English only.
Conditions:
▪ The PC has an Ethernet link to the device.
Establishing a connection:
▪ Enter into the address bar of the browser the IP address of the control unit.
Various data from the controller can be called up in the left-hand navigation bar.
HMI Display actual values in two variants and three sizes.
Events Most recent stored events (alarms, warnings, etc.)
Parameter changes Most recent parameter alterations
Command log Logs a list of certain commands, e.g. start / stop
Totalizer hourly Table of hourly-saved totalizing integrators / counters.
The minute after the full hour at which the saving occurs can be set in P22.01.
Totalizer daily Table of daily-saved totalizing integrators / counters
The time of saving from 00:00 h is set in P22.02.
Totalizer Table of totalizing integrators / counters saved on the command
Data logger 1 / 2 Table of the measured values recorded. The sampling interval can be set using
P22.03. Up to 10 process variables can be recorded; these can be selected using
P22.04 - P22.13. Recording can be activated in the operating field 'Mode'.
Tab. 13 : Function calls on the controller website
Memory depth is approx. 1,000 entries. All entries are recorded with the entry time. The table is refreshed
only when it is called up. The values can be exported into a PC file for analysis with standard programs us-
ing select-copy-paste.
The event display is highlighted by a colored rectangle. There are 3 colors, each of which has a different
meaning.
