Appendix
BV-H2464GB, 1234
- 138 -
INTECONT® Tersus Belt weigher, Instruction Manual
Schenck Process Group
Time Voltage ON: 22 h
Duty cycle of power supply
Monitoring: parameters P11.01
Time Feeder ON: 19 h
Duty cycle of scales and belt conveyor.
Monitoring: parameters P11.03
Tachometer 1 96.655 Hz
velocity sensor input frequency.
The frequency must be within the range 0.04 ... 3000 Hz.
Utilization LC 30.988 %
Load on load cells sourced from the sum of the load cell nominal ca-
pacities.
The weigh cells are overloaded if the values exceed 100 %.
The message H4: LC Input > MAX occurs upwards of 110 %.
Loadcell 1 0.383257 mV/V
Non-standardized output value of the weigh cell amplifier (gross).
The value is recorded before the belt influence compensation function
and before the delay at the dispatch point.
CSUM: Flash 1
Check sum of the scale software
CSUM: Flash calc. 1
Check sum of scales software. recalculated
Controller Magnitude 1.44 mA
Controller output as specification for the drive
Actual Tare 27.000 kg/m
Currently stored tare value
Temperature 22.5 °C
Current temperature in the equipment
Deviation abs. 0.03 %
Current value of the controller deviation
Ethernet/IP: OK
OK if Ethernet/IP option is cleared; otherwise NO
The values listed are exemplary.
18.2
18.218.2
18.2
Set option
Set optionSet option
Set option
There is the option of clearing fieldbus coupling Ethernet/IP by software. This unit issues an unambiguous
ID (the MAC address). An activation code is generated from this ID that is then keyed into the unit. If the
optional activation is required on devices which have already been delivered, the data is transferred to the
Schenck process, and the generated activation code is reported back.
The Option activate function is only accessible when the fieldbus protocol is on NO or Ethernet/IP.
