Operation
BV-H2464GB, 1234
- 18 -
INTECONT® Tersus Belt weigher, Instruction Manual
Schenck Process Group
Printer Set-
ting
Batch
Configuration and parameter functions are only accessible via password. The password is queried once the
function has been called up.
Access to some functions can be configured in the Dialog Behaviour block. Certain entries may be missing
depending upon this setting.
The appearance at the device:
Fig. 6: Display – function distributor
4.3
4.34.3
4.3
Operating in
Operating inOperating in
Operating in
Normal Operation
Normal OperationNormal Operation
Normal Operation
Switching on the totalizing
Condition:
The external release signal must be pending (selectable), P02.06 Feeder
Start must be set to OP or keyboard mode must be activated.
Turn off of totalizing
The feeder drive can be switched on and off with the keys in this field if the mode of operation and the pa-
rameterization permit it.
WARNING
A start signal will actuate the motors!
There is the danger of injury if persons are in the area of the drives. Bulk
solids can be transported and cover the following equipment.
The switch-off command is not an emergency-off, but rather is normal op-
erational shutdown.
