INTECONT® Tersus Belt weigher, Instruction Manual
Schenck Process Group
BV-H2464GB, 1234
- 137 -
18
1818
18 Appendix
AppendixAppendix
Appendix
18.1
18.118.1
18.1 Service Values
Service ValuesService Values
Service Values
Detailed information on the system is contained in the service table. The call-up does not interfere with any
weigh functions.
Setup
Service Values
Call up the function block
Scroll through the service values
Setup
Standard Values
Exit the service values
Readouts:
Vxx 2065y-yyy
Software version
2011-08-01 08:01:58
Date and time
VOL OP
Operating mode when active
(VOL = volumetric, OP = keyboard mode)
DO = 1 1 1 0 0 0 0 0 Relay Outputs Switching State
"1" = Contact closed
"0" = Contact open
DI = 1 1 1 1 - 0 1 Inputs Switching State
"1" = Contact closed
"0" = Contact open
additional for Namur signals
"+" Short circuit
"-" Cable breakage
"1" = Sensor covered
"0" = Sensor clear
Additional for legal for trade
belt weighers
"1" = Calibration switch active
"0" = Calibration switch inactive
Analog Output 1 4.15 mA
Output current of the analog output 1
