Schenck process Intecont Tersus Beltweigher User Manual

General Diagram
BV-H2464GB, 1234
- 8 -
INTECONT® Tersus Belt weigher, Instruction Manual
Schenck Process Group
1 COUNTER Pulse output for connecting an external totalizing counter
2 ANALOG Analog output
3 SERIAL Serial interfaces for the printer or second display
4 24 V Power supply
5 MOTOR Control output for belt drive
6 PREFEEDER Control output for a prefeeder
7 FULL "Full feed“ relay output for batching
8 DRIBBLE "Dribble feed" relay output
9 MAX Relay output for maximum monitoring
10 MIN Relay output for minimum monitoring
11 FAULT Relay output for alarms
12 ON/OFF Switch scales and totalizing on/off
13 RELEASE Release signal for recording totalizing
LC Load cell for ascertaining belt load
Belt speed Speed pick-up (tachometer)
Belt sensor Sensor for belt drift
3.3
3.33.3
3.3 Method of Function
Method of FunctionMethod of Function
Method of Function
A belt weigher or weighfeeder continuously weighs the quantity of material transported by a conveyor belt.
The feed rate is regulated on a weighfeeder according to a setpoint. A belt weigher only measures and it
cannot influence the feed rate.
Definitions
DefinitionsDefinitions
Definitions
Q
Belt load
The weight of the material on a meter belt
V
Speed
The speed of the conveyor belt
I
Feed rate
The quantity of material transported by the conveyor belt per unit of time
Z
Total
Amount of material transported = Feed rate x feed time
Belt load Q and speed v are continuously measured and factored together. The result is the feed rate I, from
which the flow rate is determined.

Schenck process Intecont Tersus Beltweigher Specifications

General

Brand	Schenck process
Model	Intecont Tersus Beltweigher
Category	Control Panel
Language	English
