Batching functions
INTECONT® Tersus Belt weigher, Instruction Manual
Schenck Process Group
BV-H2464GB, 1234
- 37 -
11
1111
11 Batching functions
Batching functionsBatching functions
Batching functions
Functions: Batch
Select Batch / Deselect Batch
Batch Record
Abort Batch
Batch Number
Reload
Next with Belt Empty
Batch
11.1
11.111.1
11.1 Batching mode
Batching modeBatching mode
Batching mode
A preselected quantity of material is dispatched in batching mode. When the batch setpoint is reached, the
system is switched off and the feeding process is ended.
Display:
If Batch Mode is selected, the summation symbol Ɖ appears in the header.
Relevant data in the middle and lower display zone: Batch Setpoint, Batch Actual Value and Batch Residual
Amount.
Before starting a batch, Batch Actual Value and Batch Residual Amount show the amounts reached by the
previous batch. Deselecting Batch Mode means that the displays are no longer accessible, although they
appear again with the new preselection.
The format of the display is determined by P02.07 Counter 1 Unit and also by P02.13 Z1-Numberstep, de-
pending on the application.
Preselecting batching mode
Preselecting the batching mode makes batching possible, although it does not initiate a batch.
The condition: scales OFF and the function is activated.
Batch
Select Batch
Call up the function distributor
Input theBatch Setpoint
A Batch Setpoint query occurs automatically upon preselection or can be manually initiated with after
a batch has been finished (scales OFF).
No entry can be made if batch mode is deselected or if a batch is in process.
