Printer functions
INTECONT® Tersus Belt weigher, Instruction Manual
Schenck Process Group
BV-H2464GB, 1234
- 35 -
10
1010
10 Printer functions
Printer functionsPrinter functions
Printer functions
Functions: Printer Setting
Totalizer Record
Print Parameters
Print Status Report
Batch Record
Printer Set-
ting
When printing with the Batch Record function, the Totalizer Record function adds the batch setpoint and
actual batch value to the print-out and Totalizer Printout is printed out as the heading.
The batch protocol can only be printed after completing the batch. The counter protocol is available at any
time.
The complete parameter list is printed out with the current readings using the Print Parameters function. All
inputs departing from the default readings are marked with an *. The list of all possible event messages and
the current hardware allocation is printed out as an appendix.
The printing procedure can be cancelled at any time.
10.1
10.110.1
10.1 Status Report
Status ReportStatus Report
Status Report
The Print Status Report can be printed out at any time. It provides information on the events and configura-
tion results that have occurred to date, etc. The Service Values chapter explains the specific data in detail.
The printing procedure can be cancelled at any time.
Software version
Own Address
EasyServe address information
IP Address
Ethernet address information
OP Mode
Simulation Mode
Feeder On
Volumetric Mode
Summary Alarm
Status information
Maintenance Electric
Overall duty cycle of mains voltage.
