Appendix
INTECONT® Tersus Belt weigher, Instruction Manual
Schenck Process Group
BV-H2464GB, 1234
- 139 -
Parameter
Option activate
Call up the function block
…
Key in password
Abort possible at any time
The MAC-ID (example: 00:15:84:01:03:ee) and selected option
(example:Ethernet/IP) are shown.
If there is no clearance, memorize the value and report to Schenck Process.
Code: Key in the clearance code from Schenck Process
Ethernet/IP
Message after input of a valid activation code or error message
and abort
18.3
18.318.3
18.3 Function Check
Function CheckFunction Check
Function Check
Turn on the scale
The switch-on process depends on the preselected P02.06 Feeder Start source.
Analyze any event messages that may appear and rectify the fault.
Call up the function Setup - Service Values
a) tachometer
The output frequency of the tachometer generator has to be less than 3,000 Hz when the measurement is
activated. The value must approximately correspond to the information in the data sheet. If the frequency
fluctuates substantially at a constant belt speed, the Namur sensor of the tachometer generator is probably
too far away.
b) wz
The non-standardized output value of the load cell amplifier may not be greater than 2.85 mV/V even at the
rated load of the weighbridge. It must change if the weighing platform is placed under load (e.g. the calibra-
tion weight).
Value too large:
– load cell overloaded
