Calibration functions
INTECONT® Tersus Belt weigher, Instruction Manual
Schenck Process Group
BV-H2464GB, 1234
- 27 -
8
88
8 Calibration functions
Calibration functionsCalibration functions
Calibration functions
Functions: Calibration
>0< Zero Set
LB: Pulses/Belt
TW: Tare
CW: Span Calibration Calibration
Set Time
8.1
8.18.1
8.1 Starting the calibration functions
Starting the calibration functionsStarting the calibration functions
Starting the calibration functions
▪ The adjustment programs that provide basic and subsequent calibration are available in this menu along
with the >0< Zero Set and Set Time functions.
▪ The procedure is the same for all programs.
▪ All of them are protected from unintentional operation with a password. No total will be recorded during
the run time of a program until acknowledgement; analog outputs are set to the offset amount.
Calibration
Call up the function distributor
Select the desired adjustment program
…
Key in password 7353
Afterwards you will be shown the dialog of the selected adjustment program.
8.2
8.28.2
8.2 Pulse/Belt circuit LB
Pulse/Belt circuit LB Pulse/Belt circuit LB
Pulse/Belt circuit LB
The LB: Pulses/Belt calibration program only has to be called up
▪ At initial calibration
▪ when a new belt is mounted or the belt tension has been changed substantially
▪ when one of the P02.04 Pulses per length or P02.05 Nominal Speed parameters was changed on
scales with or without speed measurement.
The amount of impulses given by the speed sensor for one belt circuit is calculated. Afterwards, the number
of impulses acts as a belt circuit identifier for the TW: Tare, CW: Span Calibration programs and zeroing.
