Calibration functions
BV-H2464GB, 1234
- 28 -
INTECONT® Tersus Belt weigher, Instruction Manual
Schenck Process Group
This program should be called up at initial calibration as the first of all adjustment programs. This also ap-
plies to scales without speed measurement.
Preconditions:
1. Measure the time for a belt circuit as precisely as possible and key in as theP03.02 Belt Circuit Time
parameters before calling up
2. The conveyor belt has to run
3. Volumetric mode (weighfeeders only)
4. Switch off batch mode
Note:
Belt drive and prefeeder are not controlled by the set-up program. The setup program will be interrupted
with a corresponding message if one of the conditions is not met.
Sequence:
Calibration
LB: Pulses/Belt
Call up the function distributor
Abort possible at any time
While the program is running, the remaining seconds of the program running time and the impulses added
up with the velocity sensor are shown in the display.
LB: Calibration active is shown in the header.
After ending the program, the mean belt speed is shown in the display over the entire running period
along with the final result of impulses/belt circuit.
There is the request 'LB: wait for Confirmation' in the header.
The results are accepted and filed in P04.06 Belt Circuit No. parameters.
The result is not taken over. Aborted ! is shown in the header.
The procedure is identical for models without no speed sensor.
Specific Messages:
Start ! if the belt is not running
