SCHUNK WBL 22.03 - Base Frame

Schunk Bahn- und Industrietechnik GmbH
Spare Parts
SB-038483-EN.docx
115 / 147
Datum: 13.02.2018
SAP.Nr.10901359
Index: -
Base Frame
POS
QTY
UNIT
SPARE PART
DESCRIPTION
SPARE
PART NO
1
2
3
4
5
Base frame compl.
1-G01.15058
10598903
1
1
PCS
Base frame WA
1-G01.15723
10598674
P
2
1
PCS
Base bearing
3-L01.4206
10482227
3
3
PCS
Limit stop
d50 h=18 M10x28
GIMPK50.18
10467249
C
R
4
3
PCS
Washer plain
10 ISO 7089 A2
10467194
C
R
5
2
PCS
Hexagon nut style 1
M10 ISO 4032 A2-70
10508618
C
R
6
1
PCS
Prevailing torque type
hex nut
M10 ISO 10511 A2-70
10508660
C
R
7
4
PCS
Support spring compl.
SB-024165
10706304
C
R
8
2
PCS
Sticker
4-G01.12955
10509363
R
1
2
2
8
7
7
3, 4, 6
3 - 5
3 - 5
SB-038488_RS_Blatt2
