Improper storage
Damages
• Always store the pantograph with the proper side up, the pan head has to be upside.
• Never store other components onto the pantograph or its package.
When storing without package:
• Mount spacers at the bottom of the insulators.
Storage inside Transportation Package
• roofed
• well ventilated
• dry
• Ambient temperature acc. to technical data ( Chapter #3)
Storage outside Transportation Package
• Plane ground
• Mount spacers with proper height at the bottom of the insulators to avoid damage
of protruding parts.
Storing several pantographs one upon the other outside the transportation
package:
• Use proper frames.
• Take additional precautions to assure that protruding parts (e.g. horns etc.) cannot
be damaged.
