Schunk Bahn- und Industrietechnik GmbH
Assembly
8 Assembly
Attachment to Vehicle Roof
The base frame must be mounted tension free onto the vehicle roof. The base tube
of the lower frame must be horizontal. If needed washers may be placed underneath
the insulators to act as shims.
Procedure:
Shut-off current supply.
Ground catenary.
Secure switch against unintended re-set.
Always keep the proper tightening torque.
Chapter #11.3.2
1. Attach insulators to vehicle roof.
2. Secure upper frame to base frame (e. g with a suitable belt).
3. Fasten pantograph at the transport hooks on base frame with a suitable
harness.
4. Fasten harness to a suitable hoisting device (e.g. crane).
No one is allowed underneath the pantograph while
transportation.
5. Lift pantograph on vehicle roof.
6. Place pantograph onto insulators on the vehicle roof.
7. Check, if the upper mounting points of the insulators fit to the base frame:
a. For longitudinal or transverse deviations loosen screw connections of
the insulators to the vehicle roof.
b. Slide insulators until the upper mounting points fit to the base frame.
c. If there are height deviations use washers between insulator and base
frame.
