SCHUNK WBL 22.03 - Interval 3 - Every Year (Max. 250.000 Km)

Schunk Bahn- und Industrietechnik GmbH
Maintenance
SB-038483-EN.docx
50 / 147
Datum: 13.02.2018
SAP.Nr.10901359
Index: -
Interval 3 – Every Year (max. 250.000 km)
• Checkup
o Static contact force ( Chapter #14.8).
o Raising and lowering time acc. to technical data ( Chapter #3).
o Screw connections for proper torque and tight fit ( Chapter #11.3.2).
o Pneumatic connections for tightness ( Chapter #11.4.7).
o Functional test of valve unit ADD ( Chapter #11.4.5.)
o Pan head suspension for easy movement and damage ( Chapter #11.4.3.2).
o Rod end of parallel guide for damage ( Chapter #11.4.2.1).
o Shunts for damage ( Chapter #11.4.6).
o Cable with terminals for damage ( Chapter #11.4.1).
o Shock absorber ( Chapter #11.4.4).
Replace damaged components ( Chapter #11.4.8).
• Cleaning ( Chapter #15)
o Insulating hoses
• Greasing ( Chapter #11.3.3)
o Cable with terminals
