3 Technical Data
Standard ............................................................................................... IEC 60494-1/2
Static contact force .......................................................................................... 80 ± 5 N
Rated current ...................................................................................................... 400 A
Nominal voltage ................................................................................ 25 kV AC (50 Hz)
Resting position ......................................................................................... 585 ±10 mm
Insulating distance resting pos. ................................................................. 262 ± 5 mm
Insulating distance working range .............................................................. 259 ± 5 mm
Min. Working height over resting position ........................................................ 100 mm
Max. Working height over resting position ..................................................... 2395 mm
Max. Extension over resting position ............................................................ 2400 mm
Total length in resting position .............................................................. 2335 ± 15 mm
Total weight .................................................................................................... 184,6 kg
Max. Speed
(Under good overhead line conditions) ........................................ max. 160 km/h
Ambient temperature ............................................................................. -10 to + 50°C
Max. Humidity ..................................................................................................... 100 %
Pan Head.......................................................................................................................
Individual suspension of collector Strips, parallel mounted
Pan Head width ............................................................................. 1800 ±10 mm
Collector Strips (2 pieces)
Width ......................................................................................................... 35 mm
Distance (middle-middle) .................................................................. 390 ± 5 mm
Material .................................................................. SK 85 Cu Composite carbon
