SCHUNK WBL 22.03 - Shock Absorber; Illustration 12: Shock Absorber

Schunk Bahn- und Industrietechnik GmbH
Pantograph Components
SB-038483-EN.docx
30 / 147
Datum: 13.02.2018
SAP.Nr.10901359
Index: -
Shock absorber
The shock absorber between lower frame and base frame compensates vibrations of
the pantograph. The stages of compression and tension are designed to assure best
contact behavior between sliding strips and catenary.
Illustration 12: Shock absorber
All components of the shock absorber are listed in the Spare Parts – List
( Chapter #17.2.9).
SB-038761_RS_Blatt1
