Parallel Guide
The parallel guide bar prevents the pan head from distorting, while the pantograph is
raised or lowered. The turning capacity of the pan head is adjusted by screwing-in
and screwing-out the rod end of the parallel guide bar. This achieves equal wear on
both sliding strips.
The component is anodized for protection of environmental influences.
Illustration 10: Parallel guide
All components of the Parallel Guide Bar are listed in the Spare Parts – List
( Chapter #17.2.7).
