Adjustment of Trend of Static Contact Force
The static contact force must be almost constantly over the whole working height.
This is achieved by the adjustment of cam.
For adjustment procedures, the damper must be removed or
else results will be falsified.
Adjustment of Cam
Illustration 45: EXAMPLE: Adjust cam
1
2
3
3
4
SB-029330_RS.idw - Blatt 11 - Rev. -
5
