SCHUNK WBL 22.03 - Illustration 24: OPEN Test Valve; Illustration 25: CLOSE Test Valve

Schunk Bahn- und Industrietechnik GmbH
Maintenance
SB-038483-EN.docx
64 / 147
Datum: 13.02.2018
SAP.Nr.10901359
Index: -
b. Release belt:
The pantograph stays in resting position.
c. Shut – off compressed air supply.
d. Fix belt between base frame and upper frame.
Illustration 24: OPEN test valve
6. CLOSE Test Valve:
a. Bring lever (2) to position CLOSED.
Illustration 25: CLOSE test valve
SB-036450_RS.idw - Blatt 4 - Rev.-
SB-036450_RS.idw - Blatt 5 - Rev.-
