Checkup of Resting Position
Procedure:
1. Lower pantograph.
2. Attach spirit level over the whole length of the pantograph.
3. Adjust spirit level at highest point of the pantograph.
4. Measurement of resting position.
5. Compare measured value to value from technical data ( Chapter #3).
The highest point of the pantograph may not exceed the
resting position.
If the measured value differs from the value of technical data:
6. Adjust resting position ( Chapter #14.4). 
