Type Tag
The type tag is located on the base frame. For questions about your pantograph
please indicate TYPE (4), DWG NO (5) and REV.NO (6).
Illustration 15: Type tag
1
SERIAL NO.
2
KOMM. NO.
3
CUSTOMER ID NO.
4
TYPE
5
DWG NO.
6
REV. NO.
7
BUILT
8
MAT. NO.
9
VOLTAGE
SB-028704_RS.idw - Blatt 1 - Rev. -
2
3
4
5
9
6
7
1
8
