Schunk Bahn- und Industrietechnik GmbH

Maintenance

SB-038483-EN.docx

68 / 147

Datum: 13.02.2018

SAP.Nr.10901359

Index: -

Overreach detection

The lifting height limitation must be checked annually for function and damage.

• Lower the pantograph.

• Activate lifting height limitation.

• Lift the pantograph pneumatically.

• Lift the pantograph only up to the specified height (Chapter #3).

• Check the pneumatic cylinder moves in and out without jerking
