Schunk Bahn- und Industrietechnik GmbH
Maintenance
Attachment:
1. Grease cable with terminals at the contact surfaces to lower frame (4), cam (3)
and cable guide (5) ( Chapter #11.3.3).
2. Place check nuts and washer (3) to cable with terminals (1).
3. Place cable with terminals (1) to lower frame (4), cam (3) and cable guide (6).
4. Place screw connection (2).
Secure cable against twisting at the terminals (S).
Only slightly tension the cable with terminals.
5. Slightly tension cable with terminals (1) with nuts and washer (2).
6. Checkup:
Flat side (A) of washers must show OUTSIDE.
Adjust washer if necessary.
7. Adjust air bellow drive ( Chapter #14.6).
