1. Assure that compressed air supply is SHUT-OFF.
2. Detach air pressure hose (2) from sliding strip and secure it against ingress of
dirt (e. g. by taping).
3. Loosen screw connection – shunts to sliding strip (3).
4. Loosen screw connections (4) and detach sliding strips (1).
Attachment:
1. Grease ( Chapter #11.3.3) new sliding strip (1).
2. Grease ( Chapter #11.3.3), place and fix ( Chapter #11.3.2) screw
connection (4).
3. Attach shunts to pan head and fix it with screw connection (3)
( Chapter #11.5.5.4).
4. Attach air pressure hose (2) to sliding strip.
5. CHECKUP: All air pressure hoses are connected to the sliding strips.
6. Check static contact force ( Chapter #14.8).
