6. Adjust shunts to following criteria:
a. Shunts may never TOUCH EACH OTHER.
b. Shunts may never TOUCH OTHER COMPONENTS of the pantograph.
c. Shunts may never BE TENSIONED.
d. Shunts MUST always HANG LOOSELY.
Move shunts in proper direction.
Slightly bend tubular lugs if necessary.
Keep distance to pantograph while performing checkup.
7. Checkup:
a. Raise and lower pantograph over whole working height.
b. Re-adjust shunts if necessary. 
