APPENDIX B – PROGRAMS
62. .
EXAMPLES OF PRINTED REPORTS
Cycle Report (normal)
Model Bravo17
S/N 03 BM 0001
Ver. SW Exxxx/BM yyyyyy
Counter 0007/0015
Selection 134c SOLID/UNWRAPPED
Temperature 134 °C
Pressure 2.10 bar
Process time 4 m i n
Stand-by L O W
Pre-vacuum SINGLE
Drying FAST
CYCLE START 19/11/02
12:14
T i m e C bar
----------------------------------------------------------
00:01 CS 079.4 +0.00
02:02 1PV 093.7 -0.80
05:48 ET 135.6 +2.15
06:02 SS 135.9 +2.17
07:02 135.6 +2.14
08:02 135.5 +2.14
09:02 135.4 +2.14
10:02 SE 135.5 +2.15
10:37 DS 104.1 +0.00
11:41 SPD 047.5 -0.90
16:08 DE 047.6 -0.84
17:12 CE 084.6 -0.04
06:32 MAX 136.0
09:59 MIN 135.4
Drying PuIses 01
CYCLE END 19/11/02
12:27
STERILIZATION: POSITIVE
OPERATOR
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
----------------------------------------------------------
Model Bravo17
S/N 03 BM 0001
Ver. SW Exxxx/BM yyyyyy
Counter 0007/0015
Selection 134c POROUS/WRAPPED
Temperature 134 °C
Pressure 2.10 bar
Process time 4 m i n
Stand-by HIGH
Pre-vacuum FRACTIONATED
Drying STANDARD
CYCLE START 19/11/02
09:52
T i m e C bar
----------------------------------------------------------
00:01 CS 075.1 -0.00
01:57 1PV 047.S -0.80
04:53 1PP 120.5 +1.00
07:00 2PV 061.1 -0.80
09:15 2PP 120.4 +0.98
11:22 3PV 061.1 -0.80
15:04 ET 135.5 +2.15
15:19 SS 135.9 +2.17
16:19 135.4 +2.14
17:18 135.5 +2.15
18:19 135.4 +2.14
19:19 SE 135.5 +2.15
19:53 DS 104.4 +0.00
20:57 SPD 048.4 -0.90
26:55 EPD 094.9 -0.86
29:15 DE 112.6 -0.47
29:43 CE 115.8 -0.04
16:20 MAX 135.9
18:11 MIN 135.4
Drying Pulses 05
CYCLE END 19/11/02
10:17
STERILIZATION: POSITIVE
OPERATOR
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cycle Report (extended)
at the operator's request
Model Bravo17
S/N 03 BM 0001
Ver. SW Exxxx/BM yyyyyy
Counter 0007/0015
Selection 134c POROUS/WRAPPED
Temperature 134 °C
Pressure 2.10 Bar
Process time 4 m i n
Stand-by HIGH
Pre-vacuum FRACTIONATED
Drying STANDARD
CYCLE START 19/11/02
09:52
T i m e T1 P T2 T3 T4
-------------------------------------------------------------------
00:01 CS 075.1 -0.00 130.9 115.2 093.4
00:11 074.9 -0.28 133.3 114.2 094.0
00:21 074.4 -0.46 146.3 113.2 094.5
00:31 074.3 -0.57 152.6 112.2 095.0
00:35 .. 074.3 -0.59 154.2 111.9 095.2
00:51 .. 078.9 -0.62 152.2 110.4 095.6
01:01 .. 074.9 -0.73 146.6 109.6 095.7
01:27 .. 047.8 -0.78 149.3 107.7 095.7
01:57 .. 047.8 -0.80 155.3 105.8 095.4
02:07 .. 076.5 -0.57 149.9 105.2 095.1
02:17 .. 081.1 -0.49 142.1 104.6 094.6
……………
……………
08:15 … 068.4 -0.76 151.8 104.7 102.3
08:22 … 061.1 -0.80 153.6 104.5 101.7
08:32 ... 097.4 +0.01 154.7 104.0 100.8
08:42 … 104.6 +0.24 148.9 103.7 101.0
……………
……………
15:04 … 135.5 +2.15 143.3 111.7 131.7
15:19 … 135.9 +2.17 148.5 113.5 132.6
15:28 … 135.3 +2.16 153.6 115.9 133.0
……………
……………
19:19 … 135.5 +2.15 157.4 126.5 132.5
19:34 … 134.4 +1.07 157.0 126.8 131.2
19:49 … 108.3 +0.25 156.4 126.8 119.9
19:53 .. 104.4 +0.00 156.1 126.6 116.2
20:04 … 094.2 - 0.50 155.1 125.9 112.4
20:19 … 069.2 -0.73 153.7 124.5 112.9
20:34 … 059.2 -0.81 152.3 123.4 113.5
20:49 … 053.8 -0.87 151.2 122.9 113.6
20:57 … 048.4 -0.90 150.9 122.7 113.5
21:04 … 047.1 -0.80 151.0 122.5 113.5
23:31 … 042.3 -0.89 153.3 122.0 112.2
……………
……………
26:55 … 094.9 -0.90 153.3 121.7 112.3
27:10 … 101.4 -0.67 154.0 121.7 112.3
27:25 … 105.4 -0.57 153.7 121.5 112.3
……………
……………
29:15 … 112.6 -0.47 149.6 119.1 111.2
29:28 … 115.2 -0.10 143.0 118.4 110.7
29:43 CE 115.8 -0.04 147.4 110.1 110.7
16:20 MAX 135.9
18:11 MI N 135.4
Drying pulses 05
CYCLE END 19/11/02
10:17
STERILIZATION: POSITIVE
OPERATOR
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
EXTENDED REPORT
REQUESTED BY THE OPERATOR
---------------------------------------------------------
Report following a
Manual Stop
Model Bravo17
S/N 03 BM 0001
Ver. SW Exxxx/BM yyyyyy
Counter 0007/0015
Selection 134c POROUS/WRAPPED
Temperature 134 °C
Pressure 2.10 bar
Process time 4 m i n
Stand-by HIGH
Pre-vacuum FRACTIONATED
Drying STANDARD
CYCLE START 19/11/02
11:13
T i m e C bar
----------------------------------------------------------
00:01 CS 077.6 +0.01
01:40 1PV 088.7 -0.80
04:40 1PP 120.6 +1.00
05:40 2PV 062.9 -0.80
07:10 2PP 135.6 +1.00
08:20 3PV 135.5 -0.80
11:20 ET 135.4 +2.15
11:39 SS 135.5 +2.17
12:39 135.5 +2.14
13:39 104.1 +2.15
14:39 047.5 +2.15
STERILIZATION: NEGATIVE
OPERATOR
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
ALARM CODE: E999
DESCRIPTION MANUAL STOP
----------------------------------------------------------
Report following a
Blackout
Model Bravo17
S/N 03 BM 0001
Ver. SW Exxxx/BM yyyyyy
Counter 0006/0012
Selection 134c CUSTOM
Temperature 134 °C
Pressure 2.10 bar
Process time 07 min
Stand-by HIGH
Pre-vacuum FRACTIONATED
Drying FAST
CYCLE START 19/11/02
15:31
BLACK OUT 19/11/02
15:45
STERILIZATION NEGATIVE
OPERATOR
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
ALARM CODE: E000
DESCRIPTION BLACK-OUT
----------------------------------------------------------
