6. CONFIGURATION
29.
Setting the printing
mode
(PRINT OPTIONS on the
ADVANCED menu)
Printer model 1
Printer model 2
When the sterilizer is equipped with a printer (optional on the Bravo17, but standard on the
Bravo17V and 21V) for recording sterilization program data, it is necessary to set the
parameters required for its proper operation.
1. Select PRINT OPTIONS using the ↵ key and the following menu appears:
→ PRINTER +
REPORT ↑
EXIT ↓
-
Select PRINTER to access the settings for the printer used, or REPORT to set the number
of copies to print and to reprint data from the last program executed.
a) Item PRINTER
The following screen appears:
→ OFF +
INTERNAL ↑
EXTERNAL ↓
EXIT -
Select OFF to deactivate the printing of data at the end of a sterilization (or test) cycle.
Select INTERNAL to enable the thermal printer set (option) inside the front of the
sterilizer. In this case, another menu opens:
→ TYPE 1 +
TYPE 2 ↑
EXIT ↓
-
Select Type 1 for the model 1 of the printer installed.
Select Type 2 for the model 2 of the printer installed.
If, on the other hand, you choose EXTERNAL, the data will be printed on an external
peripheral. Following this selection, another menu opens:
→ CR TYPE +
CR+LF TYPE ↑
CR (+FF) TYPE ↓
CR+LF (+FF) TYPE –
EXIT
Activate CR to use printers that advance the paper only on the CR (Carriage Return)
command, or CR+LF for those that require the CR+LF (Carriage Return + Line Feed)
commands, or wi t h +FF (Form-Feed) for printers that require the addition of this
command.
CONSULT THE PRINTER MANUAL TO DETERMINE THE TYPE OF COMMAND USED. IF THIS
INFORMATION IS NOT AVAILABLE, TRY PRINTING WITH THE VARIOUS OPTIONS TO
IDENTIFY THE CORRECT SETTING.
