MX-2300/2700 N/G SIMULATION 7 – 99
Sub scan
adjustment
error
10 MAIN BLACK FRONT Number error sub scan BLACK F The number of pitch data is not the specified number.
11 MAIN BLACK FRONT Pitch error sub scan BLACK F The pitch data is not in the specified allowable range.
15 SUB BLACK REAR Number error sub scan BLACK R The number of pitch data is not in the specified range.
16 SUB BLACK REAR Pitch error sub scan BLACK R The pitch data is not in the specified allowable range.
20 SUB CYAN FRONT Number error sub scan CYAN F The number of pitch data is not the specified number.
21 SUB CYAN FRONT Pitch error sub scan CYAN F The pitch data is not in the specified allowable range.
22 SUB CYAN FRONT Adjustment value error sub scan
CYAN F
The calculation result value is not in the specified allowable
range.
23 SUB CYAN FRONT Result value error sub scan CYAN F The variation of the calculation result value is over the
specified allowable range.
25 SUB CYAN REAR Number error sub scan CYAN R The number of pitch data is not the specified number.
26 SUB CYAN REAR Pitch error sub scan CYAN R The pitch data is not in the specified allowable range.
27 SUB CYAN REAR Adjustment value error sub scan
CYAN R
The calculation result value is not in the specified allowable
range.
28 SUB CYAN REAR Result value error sub scan CYAN
R
The variation of the calculation result value is over the
specified allowable range.
30 SUB MAGENTA FRONT Number error sub scan MAGENTA
F
The number of pitch data is not the specified number.
31 SUB MAGENTA FRONT Pitch error sub scan MAGENTA F The pitch data is not in the specified allowable range.
32 SUB MAGENTA FRONT Adjustment value error sub scan
MAGENTA F
The calculation result value is not in the specified allowable
range.
33 SUB MAGENTA FRONT Result value error sub scan
MAGENTA F
The variation of the calculation result value is over the
specified allowable range.
35 SUB MAGENTA REAR Number error sub scan MAGENTA
R
The number of pitch data is not the specified number.
36 SUB MAGENTA REAR Pitch error sub scan MAGENTA R The pitch data is not in the specified allowable range.
37 SUB MAGENTA REAR Adjustment value error sub scan
MAGENTA R
The calculation result value is not in the specified allowable
range.
38 SUB MAGENTA REAR Result value error sub scan
MAGENTA R
The variation of the calculation result value is over the
specified allowable range.
40 SUB YELLOW FRONT Number error sub scan YELLOW F The number of pitch data is not the specified number.
41 SUB YELLOW FRONT Pitch error sub scan YELLOW F The pitch data is not in the specified allowable range.
42 SUB YELLOW FRONT Adjustment value error sub scan
YELLOW F
The calculation result value is not in the specified allowable
range.
43 SUB YELLOW FRONT Result value error sub scan
YELLOW F
The variation of the calculation result value is over the
specified allowable range.
45 SUB YELLOW REAR Number error sub scan YELLOW R The number of pitch data is not the specified number.
46 SUB YELLOW REAR Pitch error sub scan YELLOW R The pitch data is not in the specified allowable range.
47 SUB YELLOW REAR Adjustment value error sub scan
YELLOW R
The calculation result value is not in the specified allowable
range.
48 SUB YELLOW REAR Result value error sub scan
YELLOW R
The variation of the calculation result value is over the
specified allowable range.
Main scan
adjustment
error
50 MAIN BLACK FRONT Number error main scan BLACK F The number of pitch data is not the specified number.
51 MAIN BLACK FRONT Pitch error main scan BLACK F The pitch data is not in the specified allowable range.
55 MAIN BLACK REAR Number error main scan BLACK R The number of pitch data is not in the specified range.
56 MAIN BLACK REAR Pitch error main scan BLACK R The pitch data is not in the specified allowable range.
60 MAIN CYAN FRONT
Number error main scan CYAN The number of pitch data is not the specified number.
61 MAIN CYAN FRONT
Pitch error main scan CYAN The pitch data is not in the specified allowable range.
62 MAIN CYAN FRONT Adjustment value error main scan
CYAN F
The calculation result value is not in the specified allowable
range.
63 MAIN CYAN FRONT Result value error main scan CYAN
F
The variation of the calculation result value is over the
specified allowable range.
65 MAIN CYAN REAR Number error main scan CYAN R The number of pitch data is not the specified number.
66 MAIN CYAN REAR Pitch error main scan CYAN R The pitch data is not in the specified allowable range.
67 MAIN CYAN REAR Adjustment value error main scan
CYAN R
The calculation result value is not in the specified allowable
range.
68 MAIN CYAN REAR Result value error main scan CYAN
R
The variation of the calculation result value is over the
specified allowable range.
70 MAIN MAGENTA FRONT Number error main scan MAGENTA
F
The number of pitch data is not the specified number.
71 MAIN MAGENTA FRONT Pitch error main scan MAGENTA F The pitch data is not in the specified allowable range.
72 MAIN MAGENTA FRONT Adjustment value error main scan
MAGENTA F
The calculation result value is not in the specified allowable
range.
Error
code
Error display Error content Detail of content
1
: Dec. 15 2005
1
