4.1 Parts for maintenance
82
If you are using capillary column
Septum
O-ring for glass insert
Glass insert
Graphite ferrule
Capillary column
To select a capillary column, refer to a column supplier's catalogs.
Filter for the flow controller
Hydrogen flame ionization detector (FID)
The following is the list of maintenance parts and their part numbers. All these parts are consumables.
For part numbers prefixed with "S", Shimadzu products are recommended.
Name Part No. Purpose
Silicon rubber septum (20 pcs) S201-35584 Injection port septum (lower than 350C)
Septum for high temperature (20 pcs) S221-48398-91 Injection port septum (350C or higher)
Name Part No. Purpose
Fluoride rubber O-ring (5 pcs) S036-11203-84 Standard (INJ Temp. up to 450C)
Graphite O-ring (for splitless/WBI) (4 pcs) S221-47222-91 For high temperature (INJ Temp. 350C to 450C)
Graphite O-ring (for split) (4 pcs) S221-48393-91 For high temperature (INJ Temp. 350C to 450C)
Name Part No. Purpose
Glass insert (for split) S221-41444 For split injection method
Glass insert (for splitless) S221-48335-01 For splitless injection method
Glass wool (2 g) S221-48600 To pack in glass insert
Name Part No. Purpose
Graphite ferrule G0.5 (10 pcs) S221-32126-05 Capillary column installation
Graphite ferrule G0.8 (10 pcs) S221-32126-08 Wide bore column installation
Name Part No. Purpose
Molecular sieve filter S221-34121-94 For removing contamination in carrier gas
Trap (SPLIT) S221-42559-92 Split flow line trap
Trap (PURGE) S221-42559-92 Septum purge flow line trap
Aluminum gaskets S201-35183-84 For tubing connections
Name Part No. Purpose
Jet
S221-70162-92 Jet for FID (for capillary column)
S221-70162-95 Standard jet for FID
Igniter S221-41847-93 Igniter for FID
