2.1 Verifying package
14
2.1 Verifying package
This unit consists of the following parts. Verify all items to make sure none is missing.
(1) GC-2014 main body
(2) Operation manual (this document) and instruction manual in CD-ROM
(3) Standard accessories
Accessories for models equipped with packed column (GC-2014AF, ATF, AT)
* One piece comes with the model without FID, and 3 pieces come with the models with FID.
** Only for models with FID
For part numbers prefixed with "S", Shimadzu products are recommended.
TCD accessories (only for models with TCD)
For part numbers prefixed with "S", Shimadzu products are recommended.
Type Description Part No. Qty
Tools Wrench 10 12
Tweezers, K-23
S086-03047-02
S086-16103-01
2
1
Parts Branch tube MM-MF-MF
M-type blank nut (2 pcs)
G-type blank nut (2 pcs)
Glass column joint
Insert ring
SUS column adaptor INJ side
SUS column adaptor DET side
Injection port cover
Chromatopac signal cable (wide range) 115 V
230 V
S201-48386
S221-35566-91
S221-35566-92
S221-15561-91
S221-15858-84
S221-14087-91
S221-08882-91
S221-43597-01
S221-47251-41
S221-47251-43
1*
1
1
4
2
2
2**
2
1
Consumables Aluminum gasket (100 pcs)
Silicon rubber gasket (50 pcs)
Silicon rubber septum (20 pcs)
Glass wool (2 g)
Silicon O-ring (20 pcs)
Glass insert (3.2 mm)
S201-35183-84
S201-35184
S201-35584
S221-48600
S201-47614
S221-14093
1
1
1
1
1
2
Type Description Part No. Qty
Parts Column connection parts for TCD
SUS column adaptor for TCD
Pipe MN2-GM2 (200 mm)
CAUTION label
S221-10078-92
S221-10079-93
S201-48563-20
201-48298
2
2
1
1
Consumables Graphite ferrule for TCD (10 pcs) S221-10076-91 1
