3 Installation Procedure Clarity Controls
Note: When you only change some of the already configured parts of the
Shimadzu LC-10/20 System, it is recommended to remove the system
from the given Instrument tab and add it there once more.
l Set the Ext. Start Dig. Input and Ready Dig. Output numbers ⑧ for your
acquisition card according to the wires being used for synchronization.
Caution: The Shimadzu LC-10/20 System must have all subdevices configured
on the same Instrument (cannot have parts of it on different Instruments)
and no sub- device may be left unconfigured (if any subdevice is
configured on the Instrument, all subdevices must be).
- 10 -
