Attribute
ID
Acces
s
V/NV
1
Name Description Data
type
Min. max. (default
value)
6Fh Get NV Max. Temp Operating temperature
in °C/100
UDINT -4,000
70h Get NV Min. temp Lowest operating tem‐
perature reached in
°C/100
UDINT 10,000
71h Get NV Number of start-
ups
Number of start-ups
(power on) of the
encoder
UDINT -
72h Get V LED current value Momentary internal LED
current of the sensor in
μA
UINT 200
25,000 (0)
73h Get NV Max. current value Maximum internal LED
current of the sensor
system in μA
UINT 200
74h Get NV Min. current value Minimum internal LED
current of the sensor
system in μA
UINT 25,000
75h Get V Direction change
counter
Number of changes in
the direction of rota‐
tion (the numerator
increases when the
encoder changes the
direction of rotation).
UDINT 0
76h Get V Revolution counter
forward
Number of clockwise
starts (The numerator
increases when the
encoder moves clock‐
wise).
UDINT 0
77h Get V Revolution counter
backwards
Number of counterclock‐
wise starts (The numer‐
ator increases when the
encoder moves counter‐
clockwise).
UDINT 0
78h Get V Power supply volt‐
age
Current supply voltage
in mV
UINT 9,500
30,500
(24,000)
79h Get V Max. power supply
voltage
Maximum supply volt‐
age in V (stored in
EEPROM).
UINT 0
33
(0)
7Ah Get V Preset offset value Offset value calculated
from the preset value.
9
DINT (00000000)
7Dh Set NV Endless shaft
functionality
Activates round axis
functionality
0 = Off
1 = On
BOOL (0)
7Eh Set NV Number of revolu‐
tions, nominator
Numerator for the num‐
ber of revolutions
UDINT 1
2,048
(2,048)
7Fh Set NV Number of revolu‐
tions, divisor
Denominator for the
number of revolutions
UDINT 1
65,535
(1)
80h Set NV Velocity filter inte‐
gration time
Number of measured
values from which a
mean value is formed
(scanning frequency of
the position as the
basis for calculating the
speed = 1 kHz).
10
UDINT 0
128
(1)
3 PRODUCT DESCRIPTION
32
O P E R A T I N G I N S T R U C T I O N S | AFS/AFM60 EtherNet/IP 8014213/1EF3/2021-12-08 | SICK
Subject to change without notice
