Installation
FLOWSIC600-XT · Operating Instructions · 8018846/1BHP/V2-1/2021-05 · © SICK Engineering GmbH 51
Subject to change without notice
[1] The value increases by 1 DN when using meters with 2D / SD overall length.
[2] Class 0.5 is only achieved for the 8-path meter in this configuration.
Configuration 1 (A)
OIML R137 A
Class 1.0 7 DN
Class 0.5 7 DN
2
AGA Report 9 3rd Edition, July 2017 A
“Metering package performance” according to Appendix C 7 DN
Configuration 2 (B)
OIML R137 A B C
Class 1.0 5 DN 2 DN 3 DN
Class 0.5 7 DN 2 DN 5 DN
AGA Report 9 3rd Edition, July 2017 A B C
“Metering package performance” according to Appendix C with
CPA 50E
10 DN 5 DN 5 DN
The maximum gas velocity in the pipe is limited to 40 m/s in configurations
with flow conditioner.
