MAINTENANCE AND REPAIR 7
103
8026362 / V1-0/2022-03|SICK
Subject to change without notice
SUPPLEMENTARY OPERATING INSTRUCTIONS | VMS4100/5100
7.1.7 Cleaning the cabinet
The cabinet features an integrated fan to ensure that cabinet components are adequately
cooled.
▸
Air inlets and outlets on the cabinet should be cleaned regularly with a brush.
WARNING!
RISK OF DAMAGE TO ELECTRONIC DEVICES
▸
Never use compressed air for cleaning!
▸
Only knock the dirt off the ventilation grilles or clean them with a brush.
▸
Never wet-clean the grilles.
Fig. 88: Replacing the filters at the air inlets and outlets of the cabinet
▸
Regularly check and, if necessary, replace the filter mats behind the covers for the air
inlets and outlets.
▸
Remove the covers from the air inlets and outlets. To do so, insert your finger into the
semi-circular recess in the cover.
▸
Carefully remove the cover from the front.
▸
Remove old filter mats and replace them with new ones.
 Reattach the covers the right way up and press them down until they click into place.
Cleaning
Replacing
filter mats
