7 MAINTENANCE AND REPAIR
8026362 / V1-0/2022-03|SICK
SUPPLEMENTARY OPERATING INSTRUCTIONS | VMS4100/5100
Subject to change without notice
7.2 Replacing components
7.2.1 Replacing the 2D LiDAR sensor
Part no. Meaning
1094132 LMS4421R-16000 2D LiDAR sensor with pre-mounted laser protective
cover for the VMS4100
1086802 LMS4521R-16000 2D LiDAR sensor with pre-mounted laser protective
cover for the VMS5100
WARNING!
HAZARDOUS LASER RADIATION
The 2D LiDAR sensor of the VMS4100/5100 uses a class 2 laser.
The human eye is not at risk when briefly exposed to the radiation for up to
0.25 seconds. Exposure to the laser beam for longer periods of time may cause
damage to the retina. The laser radiation is harmless to human skin.
▸
Never look directly into the laser beam.
▸
Never point the laser beam at people’s eyes.
▸
During commissioning or maintenance work, suitable eye protection must be worn.
▸
Avoid laser beam reflection caused by reflective surfaces. In particular during
mounting and alignment work.
▸
Do not open the housing.
Current national regulations regarding laser protection must be observed.
WARNING
Loss of MID conformity after replacing a component
The 2D LiDAR sensors are part of the legal for trade system.
When a component is replaced, the VMS5100 loses its legal-for-trade approval.
▸
After replacing a component, contact the manufacturer.
▸
The manufacturer will arrange for the system to be reverified after the replacement
of a component.
Replacement
device
