MAINTENANCE AND REPAIR 7
109
8026362 / V1-0/2022-03|SICK
Subject to change without notice
SUPPLEMENTARY OPERATING INSTRUCTIONS | VMS4100/5100
7.2.5 Replacing the battery in the SIM2000-2 Prime controller
A battery powers the real-time clock of the SIM2000-2 Prime controller. The battery must
be replaced when drained.
WARNING!
RISK OF INJURY FROM HOT SURFACES
Risk of burns due to hot surfaces on the controllers during operation.
▸
Do not touch hot surfaces.
▸
Wear suitable safety gloves.
Fig. 94: Position of the battery in the controller
▸
Remove the black plastic cover on the SIM2000-2 Prime controller.
▸
Remove the battery from the bracket and replace it with a new CR 1632 type battery.
▸
Put the black plastic cover back in place.
▸
Dispose of the old battery as hazardous waste as per the ROHS directives (Europe).
