3 SYSTEM DESCRIPTION
40
8026362 / V1-0/2022-03|SICK
SUPPLEMENTARY OPERATING INSTRUCTIONS | VMS4100/5100
Subject to change without notice
Measuring range and scale interval value for VMS5100 - operating condition 7
(“Singulated”, “Touching/Side-by-Side” operating modes)
Min. Max. Scale value (d) Note
Length
≥ 100 mm
≥ 4.0"
≤ 5,500 mm
≤ 216.0"
10 mm
0.4"
Longest dimension of the
measuring object
Width
≥ 100 mm
≥ 4.0"
≤ 1,200 mm
≤ 47.0"
10 mm
0.4"
Dimension of the measuring
object orthogonal to the longest
dimension
Height
≥ 20 mm
≥ 1.0"
≤ 1,100 mm
≤ 43.0"
2 mm
0.1"
Maximum height of the
measuring object relative to the
transport belt surface
Tab. 7: Measuring range and scale interval value for VMS5100 (“Singulated”, “Touching/Side-by-
Side” - operating condition 7)
Measuring range and scale interval value for VMS5100 - operating condition 8
(“Singulated”, “Touching/Side-by-Side” operating modes)
Min. Max. Scale value (d) Note
Length
≥ 200 mm
≥ 8.0"
≤ 5,500 mm
≤ 216.0"
20 mm
0.8"
Longest dimension of the
measuring object
Width
≥ 50 mm
≥ 2.0"
≤ 1,200 mm
≤ 47.0"
5 mm
0.2"
Dimension of the measuring
object orthogonal to the longest
dimension
Height
≥ 20 mm
≥ 1.0"
≤ 1,100 mm
≤ 43.0"
2 mm
0.1"
Maximum height of the
measuring object relative to the
transport belt surface
Tab. 8: Measuring range and scale interval value for VMS5100 (“Singulated”, “Touching/Side-by-
Side” operating condition 8)
Transport conditions in “Singulated” operating mode
v
min
: ≥ 0.1 m/s
v
max
: ≤ 3 m/s, start/stop operation permitted.
Minimum distance between objects: 50 mm / 2"
Transport conditions in “Touching/Side-by-Side” operating mode
v
min
: ≥ 0.1 m/s
v
max
: ≤ 3 m/s, start/stop operation permitted.
Gap between the side-by-side objects ≥ 50 mm OR
Height difference of the side-by-side objects ≥ 25 mm OR
Offset of the touching objects: ≥ 75 mm
