05.05 Connections
Siemens AG 6RX1700-0AD76 6-55
SIMOREG DC Master Operating Instructions
6.6 Fuses and commutating reactors
6.6.1 Commutating reactors
Commutating reactors can be selected from Catalog DA93.1.
The line impedance including commutating reactors must be equivalent of between 4% and 10%
short-circuit voltage. Commutating reactors can be provided by the customer to limit commutating
voltage dips in the supply system (subject to local regulations).
6.6.2 Fuses
For technical data, configuring data and dimension drawings, please refer to Catalog DA94.1.
It is essential to use "UL-listed" or "UL-recognized" fuses for protection of devices in accordance
with UL standards.
6.6.2.1 Recommended fuses for field circuit
Converter unit
Rated DC current
Max. permissible
field current
1 Siemens fuse 1 Bussmann fuse
FWP 700V ЯU
A A Order No. A Order No. A
15 3 5SD420 16 FWP-5B 5
30 5 5SD420 16 FWP-5B 5
60 to 125 10 5SD420 16 FWP-15B 15
210 to 280 15 5SD440 25 FWP-20B 20
400 to 600 25 5SD440 25 FWP-30B 30
710 to 1200 30 5SD480 30 FWP-35B 35
1500 to 2000 40 3NE1802-0
1)
40 FWP-50B 50
2200 to 3000 85 3NE8021-1
1)
100 FWP-100B 100
1) UL-recognized
6.6.2.2 Fuses for armature circuit
6.6.2.2.1 Converters 1Q: 400V, 575V, 690V, 830V and 950V
Converter
Order No.
C / V 3 line fuses
Siemens ЯU
Order No. C / V
A / V A / V
6RA7018-6DS22 30 / 400 3NE8003-1 35 / 690
6RA7025-6DS22 60 / 400 3NE1817-0 50 / 690
6RA7025-6GS22 60 / 575 3NE1817-0 50 / 690
6RA7028-6DS22 90 / 400 3NE1820-0 80 / 690
6RA7031-6DS22 125 / 400 3NE1021-0 100 / 690
6RA7031-6GS22 125 / 575 3NE1021-0 100 / 690
6RA7075-6DS22 210 / 400 3NE3227 250 / 1000
6RA7075-6GS22 210 / 575 3NE3227 250 / 1000
6RA7078-6DS22 280 / 400 3NE3231 350 / 1000
6RA7081-6DS22 400 / 400 3NE3233 450 / 1000
6RA7081-6GS22 400 / 575 3NE3233 450 / 1000
6RA7085-6DS22 600 / 400 3NE3336 630 / 1000
6RA7085-6GS22 600 / 575 3NE3336 630 / 1000
6RA7087-6DS22 850 / 400 3NE3338-8 800 / 800
6RA7087-6GS22 800 / 575 3NE3338-8 800 / 800
6RA7086-6KS22 720 / 690 3NE3337-8 710 / 900
