05.05 Connections
Siemens AG 6RX1700-0AD76 6-57
SIMOREG DC Master Operating Instructions
6.6.2.2.3 Converters 4Q: 400V, 575V, 690V, 830V and 950V
Converter
Order No.
C / V 3 line fuses
Siemens ЯU
1 DC fuse
Siemens ЯU
Order No. I / U Order No. C / V
A / V A / V A / V
6RA7013-6DV62 15 / 400 3NE1814-0 20 / 690 3NE1814-0 20 / 690
6RA7018-6DV62 30 / 400 3NE8003-1 35 / 690 3NE4102 40 / 1000
6RA7025-6DV62 60 / 400 3NE1817-0 50 / 690 3NE4120 80 / 1000
6RA7025-6GV62 60 / 575 3NE1817-0 50 / 690 3NE4120 80 / 1000
6RA7028-6DV62 90 / 400 3NE1820-0 80 / 690 3NE4122 125 / 1000
6RA7031-6DV62 125 / 400 3NE1021-0 100 / 690 3NE4124 160 / 1000
6RA7031-6GV62 125 / 575 3NE1021-0 100 / 690 3NE4124 160 / 1000
6RA7075-6DV62 210 / 400 3NE3227 250 / 1000 3NE3227 250 / 1000
6RA7075-6GV62 210 / 575 3NE3227 250 / 1000 3NE3227 250 / 1000
6RA7078-6DV62 280 / 400 3NE3231 350 / 1000 3NE3231 350 / 1000
6RA7081-6DV62 400 / 400 3NE3233 450 / 1000 3NE3233 450 / 1000
6RA7081-6GV62 400 / 575 3NE3233 450 / 1000 3NE3233 450 / 1000
6RA7085-6DV62 600 / 400 3NE3336 630 / 1000 3NE3336 630 / 1000
6RA7085-6GV62 600 / 575 3NE3336 630 / 1000 3NE3336 630 / 1000
6RA7087-6DV62 850 / 400 3NE3338-8 800 / 800 3NE3334-0B
1)
500 / 1000
6RA7087-6GV62 850 / 575 3NE3338-8 800 / 800 3NE3334-0B
1)
500 / 1000
6RA7086-6KV62 760 / 690 3NE3337-8 710 / 900 3NE3334-0B
1)
500 / 1000
1) Two fuses connected in parallel
Converter
Order No.
C / V Branch fuses
Siemens ЯU
Qty. Order No. C / V
A / V A / V
6RA7091-6DV62 1200 / 400 6 3NE3338-8 800 / 800
6RA7090-6GV62 1100 / 575 6 3NE3338-8 800 / 800
6RA7090-6KV62 1000 / 690 6 3NE3337-8 710 / 900
6RA7088-6LV62 950 / 830 6 3NE3337-8 710 / 900
6RA7093-4DV62 1600 / 400 6 6RY1702-0BA02 1000 / 660
6RA7093-4GV62 1600 / 575 6 6RY1702-0BA02 1000 / 660
6RA7093-4KV62 1500 / 690 6 6RY1702-0BA03 1000 / 1000
6RA7093-4LV62 1500 / 830 6 6RY1702-0BA03 1000 / 1000
6RA7095-4DV62 2000 / 400 6 6RY1702-0BA01 1250 / 660
6RA7095-4GV62 2000 / 575 6 6RY1702-0BA01 1250 / 660
6RA7095-4KV62 2000 / 690 12 6RY1702-0BA04 630 / 1000
6RA7095-4LV62 1900 / 830 12 6RY1702-0BA04 630 / 1000
6RA7096-4GV62 2200 / 575 6 6RY1702-0BA05 1500 / 660
6RA7096-4MV62 2200 / 950 12 6RY1702-0BA07 800 / 1250
6RA7097-4KV62 2600 / 690 12 6RY1702-0BA08 1000 / 1000
6RA7097-4GV62 2800 / 575 12 6RY1702-0BA08 1000 / 1000
6RA7098-4DV62 3000 / 400 12 6RY1702-0BA08 1000 / 1000
Branch fuses are included in converter, external semiconductor fuses are not needed.
