05.05 Description
Siemens AG 6RX1700-0AD76 3-23
SIMOREG DC Master Operating Instructions
3.4.18 Converters 3AC 575V, 60A to 600A, 4Q
Order No. 6RA70 . . – 6GV62
25 31 75 81 85
Rated supply voltage armature
1)
V 3AC 575 (+10% / – 20%)
Rated input current armature
2)
A 50 104 175 332 498
Rated supply voltage electronics
power supply
V 2AC 380 (– 25%) to 460 (+15%); I
n
=1A or
1AC 190 (– 25%) to 230 (+15%); I
n
=2A
(– 35% for 1min)
Rated supply voltage fan V DC24V
internal
3AC 400 (±15%) 50Hz
3AC 460 (±10%) 60Hz
Fan rated current A 0.3
8)
Air flow rate m
3
/h 100 570
Fan noise level dBA 40 73
Rated supply voltage field
1)
V 2AC 460 (+15% / – 20%)
Rated frequency Hz 45 to 65
10)
Rated DC voltage
1)
V 600
Rated DC current A 60 125 210 400 600
Overload capability
6)
max. 180% of rated DC current
Rated output kW 36 75 126 240 360
Power loss at rated DC current
(approx.)
W 265 455 730 1550 1955
Rated DC voltage field
1)
V max. 375
Rated DC current field A 10 15 25
Operational ambient temperature °C 0 to 45 at I
rated
3)
self-cooled
0 to 40 at I
rated
3)
forced-cooled
Storage and transport
temperature
°C – 25 to +70
Installation altitude above sea level
≤ 1000 m at rated DC current
4)
Control stability ∆n = 0.006% of the rated motor speed, valid for pulse encoder operation and
digital setpoint
∆n = 0.1% of the rated motor speed, valid for analog tacho or analog
setpoint
5)
Environmental class
DIN IEC 60 721-3-3
3K3
Degree of protection DIN EN 60529 IP00
Dimensions (HxWxD) mm 385x265x283 625x268x318
Dimension diagram see Section 5.1.10 5.1.11
Weight (approx.) kg 14 16 30
Explanation at end of list of tables
