SIMOREG DC Master Operating Instructions
2.4 Ordering information for options using codes
SIMOREG converter order no. with
suffix Z and
codes (several codes together)
and/or
plaintext (if required)
Options Codes Order No.
Technology software in the basic converter ("Free function
blocks")
S00 6RX1700-0AS00
Module terminal expansion (CUD2) K00 6RX1700-0AK00
DriveMonitor PC - PMU (RS232) connecting cable, 3m 6SX7005-0AB00
User-friendly operator control panel (OP1S) 6SE7090-0XX84-2FK0
AOP1 adapter for mounting OP1A in cubicle door, including
5 m connecting cable
6SX7010-0AA00
PMU-OP1S connecting cable, 3m 6SX7010-0AB03
PMU-OP1S connecting cable, 5m 6SX7010-0AB05
LBA Local bus adapter for the electronics box
LBA is always needed to install supplementary boards
(see Section 5.3.2)
K11 6SE7090-0XX84-4HA0
ADB Adapter board
ADB is always needed to install CBC, CBP, EB1, EB2,
SBP and SLB boards
K01, K02
5)
6SE7090-0XX84-0KA0
SBP Pulse encoder evaluation board
1) 2) 3)
(miniature-format board; ADB required)
C14, C15
C16, C17
5)
6SX7010-0FA00
EB1 Terminal expansion board
3)
(miniature-format board; ADB required)
G64, G65
G66, G67
5)
6SE7090-0XX84-0KB0
EB2 Terminal expansion board
3)
(miniature-format board; ADB required)
G74, G75
G76, G77
5)
6SE7090-0XX84-0KC0
SLB SIMOLINK board
1) 3)
(miniature-format board; ADB required)
G44, G45
G46, G47
5)
6SX7010-0FJ00
CBP2 Communications board with interface for SINEC- L2-
DP, (PROFIBUS)
1) 3)
(miniature-format board; ADB required)
G94, G95
G96, G97
5)
6SX7010-0FF05
CBC Communications board with interface for CAN protocol
1) 3)
(miniature-format board; ADB required)
G24, G25
G26, G27
5)
6SX7010-0FG00
CBD Communications board with interface for DeviceNet
protocol
1) 3)
(miniature-format board; ADB required)
G54, G55
G56, G57
5)
6SX7010-0FK00
SCB1 Serial Communication Board 1 (Master for SCI1 and
SCI2 with FO link)
3) 4)
6SE7090-0XX84-0BC0
SCI1 Serial Communication Interface 1
(terminal expansion with FO link to SCB1) for
attachment to DIN EN 50022 rail
4)
6SE7090-0XX84-3EA0
