05.05 Description
Siemens AG 6RX1700-0AD76 3-29
SIMOREG DC Master Operating Instructions
3.4.24 Converters 3AC 690V, 2600A, 1Q / 4Q
Order No..
6RA7097–4KS22-0 6RA7097–4KV62-0
Rated supply voltage armature
1)
V 3AC 690 (+10% / – 20%)
Rated input current armature
2)
A 2155 2155
Rated supply voltage electronics
power supply
V 2AC 380 (– 25%) to 460 (+15%); I
n
=1A or
1AC 190 (– 25%) to 230 (+15%); I
n
=2A
(– 35% for 1min)
Rated supply voltage fan V 3AC 400 (±10%) 50Hz
3AC 460 (±10%) 60Hz
3AC 400 (±10%) 50Hz
3AC 460 (±10%) 60Hz
50Hz 60Hz 50Hz 60Hz
Fan rated current A 1.0
9)
1.25
9)
1.0
9)
1.25
9)
Air flow rate m
3
/h 2400 2400 2400 2400
Fan noise level dBA 83 87 83 87
Rated supply voltage field
1)
V 2AC 460 (+15% / – 20%)
Rated frequency Hz 45 to 65
10)
Rated DC voltage
1)
V
830 725
Rated DC current A 2600 2600
Overload capability
6)
max. 180% of rated DC current
Rated output kW
2158 1885
Power loss at rated DC current
(approx.)
kW 10.33 10.33
Rated DC voltage field
1)
V
max. 375
Rated DC current field A
85
Operational ambient temperature °C 0 to 40 at I
rated
3)
forced-cooled
Storage and transport
temperature
°C – 25 to +70
Installation altitude above sea level
≤ 1000 m at rated DC current
4)
Control stability ∆n = 0.006% of the rated motor speed, valid for pulse encoder operation and
digital setpoint
∆n = 0.1% of the rated motor speed, valid for analog tacho or analog
setpoint
5)
Environmental class
DIN IEC 60 721-3-3
3K3
Degree of protection DIN EN 60529 IP00
Dimensions (HxWxD) mm 880x450x500
Dimension diagram see Section 5.1.8 5.1.15
Weight (approx.) kg 125 145
Explanation at end of list of tables
