Description 05.05
3-14 Siemens AG 6RX1700-0AD76
SIMOREG DC Master Operating Instructions
3.4.9 Converters 3AC 575V, 800A to 2200A, 1Q
Order No. 6RA70 . . – 6GS22 6RA70 . . – 4GS22
87 90 93 95 96
Rated supply voltage armature
1)
V 3AC 575 (+10% / – 20%)
Rated input current armature
2)
A 663 829 1326 1658 1824
Rated supply voltage electronics
power supply
V 2AC 380 (– 25%) to 460 (+15%); I
n
=1A or
1AC 190 (– 25%) to 230 (+15%); I
n
=2A
(– 35% for 1min)
Rated supply voltage fan V 3AC 400 (±15%) 50Hz
3AC 460 (±10%) 60Hz
3AC 400 (±10%) 50Hz
3AC 460 (±10%) 60Hz
3AC 400 (±10%) 50Hz
3AC 460 (±10%) 60Hz
50Hz 60Hz 50Hz 60Hz
Fan rated current A 0.3
8)
1.0
9)
1.25
9)
1.0
9)
1.25
9)
Air flow rate m
3
/h 570 1300 1300 2400 2400
Fan noise level dBA 73 83 87 83 87
Rated supply voltage field
1)
V 2AC 460 (+15% / – 20%)
Rated frequency Hz 45 to 65
10)
Rated DC voltage
1)
V 690
Rated DC current A 800 1000 1600 2000 2200
Overload capability
6)
max. 180% of rated DC current
Rated output kW 552 690 1104 1380 1518
Power loss at rated DC current
(approx.)
W 2638 4130 5942 7349 7400
Rated DC voltage field
1)
V max. 375
Rated DC current field A 30 40 85
Operational ambient temperature °C 0 to 40 at I
rated
3)
forced-cooled
Storage and transport
temperature
°C – 25 to +70
Installation altitude above sea level
≤ 1000 m at rated DC current
4)
Control stability ∆n = 0.006% of the rated motor speed, valid for pulse encoder operation and digital
setpoint
∆n = 0.1% of the rated motor speed, valid for analog tacho or analog
setpoint
5)
Environmental class
DIN IEC 60 721-3-3
3K3
Degree of protection DIN EN 60529 IP00
Dimensions (HxWxD) mm 700x268x362 780x410x362 880x450x500
Dimension diagram see Section 5.1.5 5.1.6 5.1.7
Weight (approx.) kg 40 80 125
Explanation at end of list of tables
