01.04 Installation
Siemens AG 6RX1700-0AD76 5-3
SIMOREG DC Master Operating Instructions
5.1 Dimension diagrams for standard devices
5.1.1 Converters: 3AC 400V and 460V, 30A, 1Q
10
10101010
s
1W11V1
1U1
1D1 1C1
15
385
350
366
70
239
227
60
265 230
V8
V7
V5+V2V1+V4 V3+V6
T2 T3
X300
XF1 XF2
100
1)
100
1)
for M6
17.5
112.5
12.5
63.5
1) Minimum clearance for air circulation An adequate cooling air supply must be provided
Tightening torque for customer connections:
1U1, 1V1, 1W1, 1C1, 1D1 = 1,5 Nm
= 25 Nm
