Siemens 6RA7086-6KS22

Description 05.05
3-20 Siemens AG 6RX1700-0AD76
SIMOREG DC Master Operating Instructions
3.4.15 Converters 3AC 460V, 30A to 125A, 4Q
Order No. 6RA70 . . – 6FV62
18 25 28 31
Rated supply voltage armature
1)
V 3AC 460 (+15% / – 20%)
Rated input current armature
2)
A 25 50 75 104
Rated supply voltage electronics
power supply
V 2AC 380 (– 25%) to 460 (+15%); I
n
=1A or
1AC 190 (– 25%) to 230 (+15%); I
n
=2A
(– 35% for 1min)
Rated supply voltage field
1)
V 2AC 460 (+15% / – 20%)
Rated frequency Hz 45 to 65
10)
Rated DC voltage
1)
V 480
Rated DC current A 30 60 90 125
Overload capability
6)
max. 180% of rated DC current
Rated output kW 14.4 28.8 43 60
Power loss at rated DC current
(approx.)
W 172 248 328 417
Rated DC voltage field
1)
V max. 375
Rated DC current field A 5 10
Operational ambient temperature °C 0 to 45 at I
rated
3)
self-cooled
Storage and transport
temperature
°C – 25 to +70
Installation altitude above sea level
≤ 1000 m at rated DC current
4)
Control stability ∆n = 0.006% of the rated motor speed, valid for pulse encoder operation and
digital setpoint
∆n = 0.1% of the rated motor speed, valid for analog tacho or analog
setpoint
5)
Environmental class
DIN IEC 60 721-3-3
3K3
Degree of protection DIN EN 60529 IP00
Dimensions (HxWxD) mm 385x265x239 385x265x313
Dimension diagram see Section 5.1.9 5.2.5
Weight (approx.) kg 11 15 15 17
Explanation at end of list of tables
